voytek
Joined: 24 Nov 2009
Posts: 891
|
 Posted: Sat Jun 21, 2008 2:37 am Post subject: Show me your bokeh |
 |
|
voytek wrote:
I tried to find such topic, I couldn't find it. If it already exists let me know, I will remove it.
Today I received Auto Yashinon-DX 1.4/50
Here we go:
#1
#2
#3
_________________
Cheers, Voytek |
|
| Back to top |
|
 |
Bob
Joined: 15 Mar 2007
Posts: 675
Location: Wentzville, Mo.
Expire: 2011-12-08
|
| Posted: Sat Jun 21, 2008 2:52 am Post subject: |
|
|
Bob wrote:
Very nice
_________________
Bob
"In terms of addiction, there is nothing more powerful than men's toys."
Sammy Davis Jr. |
|
| Back to top |
|
|
Xpres
Joined: 11 Dec 2007
Posts: 965
Location: UK
Expire: 2014-10-28
|
| Posted: Sat Jun 21, 2008 8:15 am Post subject: |
|
|
Xpres wrote:
A collection of bokeh then...
Here's one from a zuiko 55/1.2, a lens I use a lot but usualy for portraits. This duck was under a picnic table yesterday - quite dark so I used the pop up flash as fill in but the speed was too slow so a bit of blur is evident. The aperture was still on 1.2.
This is not typical from this lens, I suppose it's something to do with the grass and it's closeness to the duck. Normally the backgrounds are a little further away.
_________________
Film... and sometimes SD14, 5D2 and some other suff! |
|
| Back to top |
|
|
kuuan
Joined: 14 Jan 2008
Posts: 4588
Location: right now: Austria
Expire: 2014-12-26
|
| Posted: Sat Jun 21, 2008 1:05 pm Post subject: |
|
|
kuuan wrote:
front and back out of focus areas,
Super Takumar 50mm f1.4:
S.M.C. Macro Takumar 50mm f4:
( I sometimes worry about this big size, I hope it is OK. I host my photos at flickr in original size and there I get options to link various sizes, this one here is 'large' and 'medium' I feel is too small )
_________________
my photos on flickr: https://www.flickr.com/photos/kuuan/collections |
|
| Back to top |
|
|
vilva
Joined: 04 Mar 2007
Posts: 785
Location: Porvoo/Borgå, Finland
Expire: 2015-05-27
|
| Posted: Sat Jun 21, 2008 1:58 pm Post subject: |
|
|
vilva wrote:
Here are some of my Radionar test shots. In the first one, the front cell was set at 1m and the focus with a variable close-up ring to about 3m. The result was slightly soft focus and a very Gaussian bokeh, note the highlights at the cathedral (NB. the sky was rather cloudy and the sunlight very weak.)
Setting the front cell to 2m will decrease the softness and make the bokeh somewhat less Gaussian. The first, very slight artifacts appear:
A similar test pair with a different subject. Note the farthest ropes of the rigging.
Finally two shots where the subject is somewhat further away. The result is rather picturesque:
The dual focusing system has a lot of potential for softness and bokeh control, but for the full range of setup combinations I have to carry two interchangeable main focusing devices, both the adjustable close-up ring and a bellows. The closest focusing distance with the ring is rather long when the front cell is set at infinity, which rather restricts the adjustment range for nearby subjects. With the bellows, infinity focus can only be achieved when the front cell is set at infinity, which limits the soft focus adjustment capability for faraway subjects (the bokeh doesn't matter at infinity as there is no background.)
Veijo
_________________
Mainly Schneider-Kreuznach Radionar (1938), VPK Meniscus Achromat (1915), TTH Cooke Anastigmat (1917), TTH Cooke Aviar (1937), Goerz Dopp-Anastigmat III Dagor (1912), Voigländer Heliar (1928) or Aldis Uno Series III (1903 design) mounted on EOS 5D or EOS 350D |
|
| Back to top |
|
|
Nesster
Joined: 24 Apr 2008
Posts: 5886
Location: NJ, USA
Expire: 2014-02-20
|
| Posted: Sat Jun 21, 2008 4:56 pm Post subject: |
|
|
Nesster wrote:
Kuuan that Macro Takumar shot is totally awesome, I just spent 5 minutes just looking at it.
_________________
-Jussi
Camera photos
Print Photographica
|
|
| Back to top |
|
|
vilva
Joined: 04 Mar 2007
Posts: 785
Location: Porvoo/Borgå, Finland
Expire: 2015-05-27
|
| Posted: Sat Jun 21, 2008 5:41 pm Post subject: |
|
|
vilva wrote:
A couple of Heliar examples displaying different qualities:
Veijo
_________________
Mainly Schneider-Kreuznach Radionar (1938), VPK Meniscus Achromat (1915), TTH Cooke Anastigmat (1917), TTH Cooke Aviar (1937), Goerz Dopp-Anastigmat III Dagor (1912), Voigländer Heliar (1928) or Aldis Uno Series III (1903 design) mounted on EOS 5D or EOS 350D |
|
| Back to top |
|
|
Xpres
Joined: 11 Dec 2007
Posts: 965
Location: UK
Expire: 2014-10-28
|
| Posted: Sat Jun 21, 2008 9:29 pm Post subject: |
|
|
Xpres wrote:
The bokeh from the duck shot above made me wonder about the zuiko 55/1.2 so I tried a few flower shots this afternoon.
All wide open for maximum effect. Nothing as weird as the duck though.
_________________
Film... and sometimes SD14, 5D2 and some other suff! |
|
| Back to top |
|
|
Nesster
Joined: 24 Apr 2008
Posts: 5886
Location: NJ, USA
Expire: 2014-02-20
|
| Posted: Sun Jun 22, 2008 1:04 am Post subject: |
|
|
Nesster wrote:
Tamron-f 35mm 2.8, this is an old fashioned lens
Tamron SP 35-80 2.8-3.8
Yashinon DX 35 2.8
Vivitar 28mm tx f/2.5
_________________
-Jussi
Camera photos
Print Photographica
Last edited by Nesster on Sun Jun 22, 2008 11:55 am; edited 1 time in total |
|
| Back to top |
|
|
Nesster
Joined: 24 Apr 2008
Posts: 5886
Location: NJ, USA
Expire: 2014-02-20
|
| Posted: Sun Jun 22, 2008 1:08 am Post subject: |
|
|
Nesster wrote:
Toenails our cat died last year, I remembered this photo because of the great Zuiko pics above... This is with the 85mm f/2.
_________________
-Jussi
Camera photos
Print Photographica
|
|
| Back to top |
|
|
patrickh
Joined: 23 Aug 2007
Posts: 8572
Location: Oregon
Expire: 2011-11-18
|
| Posted: Sun Jun 22, 2008 5:05 am Post subject: |
|
|
patrickh wrote:
These are all great examples of boke. Some I like some I dont - boke I find is a very subjective issue. Persoanlly I prefer the "creamier" variety.
patrickh
_________________
DSLR: Nikon D300 Nikon D200 Nex 5N
MF Zooms: Kiron 28-85/3.5, 28-105/3.2, 75-150/3.5, Nikkor 50-135/3.5 AIS // MF Primes: Nikkor 20/4 AI, 24/2 AI, 28/2 AI, 28/2.8 AIS, 28/3.5 AI, 35/1.4 AIS, 35/2 AIS, 35/2.8 PC, 45/2.8 P, 50/1.4 AIS, 50/1.8 AIS, 50/2 AI, 55/2.8 AIS micro, 55/3.5 AI micro, 85/2 AI, 100/2,8 E, 105/1,8 AIS, 105/2,5 AIS, 135/2 AIS, 135/2.8 AIS, 200/4 AI, 200/4 AIS micro, 300/4.5 AI, 300/4.5 AI ED, Arsat 50/1.4, Kiron 28/2, Vivitar 28/2.5, Panagor 135/2.8, Tamron 28/2.5, Tamron 90/2.5 macro, Vivitar 90/2.5 macro (Tokina) Voigtlander 90/3.5 Vivitar 105/2.5 macro (Kiron) Kaleinar 100/2.8 AI Tamron 135/2.5, Vivitar 135/2.8CF, 200/3.5, Tokina 400/5,6
M42: Vivitar 28/2.5, Tamron 28/2.5, Formula5 28/2.8, Mamiya 28/2.8, Pentacon 29/2.8, Flektogon 35/2.4, Flektogon 35/2.8, Takumar 35/3.5, Curtagon 35/4, Takumar 50/1.4, Volna-6 50/2.8 macro, Mamiya 50/1.4, CZJ Pancolar 50/1,8, Oreston 50/1.8, Takumar 50/2, Industar 50/3.5, Sears 55/1.4, Helios 58/2, Jupiter 85/2, Helios 85/1.5, Takumar 105/2.8, Steinheil macro 105/4.5, Tamron 135/2.5, Jupiter 135/4, CZ 135/4, Steinheil Culminar 135/4,5, Jupiter 135/3.5, Takumar 135/3.5, Tair 135/2.8, Pentacon 135/2.8, CZ 135/2.8, Taika 135/3.5, Takumar 150/4, Jupiter 200/4, Takumar 200/4
Exakta: Topcon 100/2.8(M42), 35/2.8, 58/1.8, 135/2.8, 135/2.8 (M42), Kyoei Acall 135/3.5
C/Y: Yashica 28/2.8, 50/1.7, 135/2.8, Zeiss Planar 50/1.4, Distagon 25/2.8
Hexanon: 28/3.5, 35/2.8, 40/1.8, 50/1.7, 52/1.8, 135/3.2, 135/3.5, 35-70/3.5, 200/3.5
P6 : Mir 38 65/3.5, Biometar 80/2.8, Kaleinar 150/2.8, Sonnar 180/2.8
Minolta SR: 28/2.8, 28/3.5, 35/2.8, 45/2, 50/2, 58/1.4, 50/1.7, 135/2.8, 200/3.5
RF: Industar 53/2.8, Jupiter 8 50/2
Enlarg: Rodagon 50/5,6, 80/5,6, 105/5.6, Vario 44-52/4, 150/5.6 180/5.6 El Nikkor 50/2,8,63/2.8,75/4, 80/5,6, 105/5.6, 135/5.6 Schneider 60/5.6, 80/5.6, 80/4S,100/5.6S,105/5.6,135/5.6, 135/5.6S, 150/5.6S, Leica 95/4 |
|
| Back to top |
|
|
kuuan
Joined: 14 Jan 2008
Posts: 4588
Location: right now: Austria
Expire: 2014-12-26
|
| Posted: Sun Jun 22, 2008 5:14 am Post subject: |
|
|
kuuan wrote:
| vilva wrote: |
The dual focusing system has a lot of potential for softness and bokeh control, but for the full range of setup combinations I have to carry two interchangeable main focusing devices, both the adjustable close-up ring and a bellows. The closest focusing distance with the ring is rather long when the front cell is set at infinity, which rather restricts the adjustment range for nearby subjects. With the bellows, infinity focus can only be achieved when the front cell is set at infinity, which limits the soft focus adjustment capability for faraway subjects (the bokeh doesn't matter at infinity as there is no background.)
Veijo |
the dual focusing system sounds very interesting ( never have had haerd of it before..)
I try to understand it, difficult with my limited experience.
Could you be so kind and offer a photos of how your set up looks like?
I like all your samples, best even the later ones, e.g
| Nesster wrote: |
| Kuuan that Macro Takumar shot is totally awesome, I just spent 5 minutes just looking at it. |
wow, thank's very much Nesster.
I very much like your sample taken with the Yashinon:
Yashinon..once again
All the samples of Yashinons I have seen are quite outstanding, must get one down the road: anybody knows which Yashinons are regarded most highly?
best regards,
Andreas
_________________
my photos on flickr: https://www.flickr.com/photos/kuuan/collections |
|
| Back to top |
|
|
Katastrofo
Joined: 26 Feb 2007
Posts: 10410
Location: USA
Expire: 2013-11-19
|
| Posted: Sun Jun 22, 2008 5:39 am Post subject: |
|
|
Katastrofo wrote:
Andreas, congrats again on the Takumar 50/1.4! Really like the foreground/
background bokeh in that shot! The term "bokeh" is Japanese, how appropriate.
Some great shots from all of you! Thanks for sharing!
Bill |
|
| Back to top |
|
|
aoleg
Joined: 22 Feb 2008
Posts: 1402
Location: Berlin, DE
|
| Posted: Sun Jun 22, 2008 9:08 am Post subject: |
|
|
aoleg wrote:
| vilva wrote: |
| Here are some of my Radionar test shots. |
These shots look amazing and very different from modern, conventional lenses. I'd like to see your setup, too. Wonder if it's possible to assemble one.
_________________
List of lenses |
|
| Back to top |
|
|
Nesster
Joined: 24 Apr 2008
Posts: 5886
Location: NJ, USA
Expire: 2014-02-20
|
| Posted: Sun Jun 22, 2008 12:00 pm Post subject: |
|
|
Nesster wrote:
[quote="kuuan"]
| vilva wrote: |
the dual focusing system sounds very interesting ( never have had haerd of it before..)
I try to understand it, difficult with my limited experience.
Could you be so kind and offer a photos of how your set up looks like?
Yashinon..once again
All the samples of Yashinons I have seen are quite outstanding, must get one down the road: anybody knows which Yashinons are regarded most highly?
best regards,
Andreas |
Andreas,
My other Yashinon is a 135/2.8. It isn't the best 135 out there.
While I've not managed as extensive experience as Veijo, I do have an old lens hooked to the far end of a bellows.
What he's talking about - most of the folding cameras had front cell focusing. That is, you turned the front element forwards to focus closer. Now, when you mount this lens on a bellows, you can move the bellows forward to focus closer, and/or you can turn the front cell.
-Jussi
_________________
-Jussi
Camera photos
Print Photographica
|
|
| Back to top |
|
|
vilva
Joined: 04 Mar 2007
Posts: 785
Location: Porvoo/Borgå, Finland
Expire: 2015-05-27
|
| Posted: Sun Jun 22, 2008 1:48 pm Post subject: |
|
|
vilva wrote:
| aoleg wrote: |
| vilva wrote: |
| Here are some of my Radionar test shots. |
These shots look amazing and very different from modern, conventional lenses. I'd like to see your setup, too. Wonder if it's possible to assemble one. |
Thanks
Here is the setup used for the above photos:
I have glued the Radionar (still mounted in the original shutter set at T) to a short M42 macro extension tube so that it is easy to change it between an M42 bellows and the Asahi Pentax Adjustable Close-Up Ring shown in the photo. The front cell of the lens is mostly used to adjust the image quality and the adjustable close-up ring to focus, which method allows any setting between a "normal" and a soft focus/bokeh. Here is an example pair of photos:
and another couple of shots just to show the leeway:
When extreme close-ups aren't desired or the highest possible contrast or resolution, this is one of my favorite lens systems, a most flexible one as you can see.
Veijo
_________________
Mainly Schneider-Kreuznach Radionar (1938), VPK Meniscus Achromat (1915), TTH Cooke Anastigmat (1917), TTH Cooke Aviar (1937), Goerz Dopp-Anastigmat III Dagor (1912), Voigländer Heliar (1928) or Aldis Uno Series III (1903 design) mounted on EOS 5D or EOS 350D |
|
| Back to top |
|
|
kuuan
Joined: 14 Jan 2008
Posts: 4588
Location: right now: Austria
Expire: 2014-12-26
|
| Posted: Sun Jun 22, 2008 2:06 pm Post subject: |
|
|
kuuan wrote:
| vilva wrote: |
Here is the setup used for the above photos:
I have glued the Radionar (still mounted in the original shutter set at T) to a short M42 macro extension tube so that it is easy to change it between an M42 bellows and the Asahi Pentax Adjustable Close-Up Ring shown in the photo. The front cell of the lens is mostly used to adjust the image quality and the adjustable close-up ring to focus, which method allows any setting between a "normal" and a soft focus/bokeh.
Veijo |
looks great, just as do your photos, very interesting set up indeed!
could you elucidate further on your settings, e.g. comparing the first to the second photo of in your last post?
Viejo, tell me, do you know for how much this Pentax ajustable Close-up Ring usually sells for?
I had just had 'found' one in a shop here, it was the first time I ever saw such a thing, and that just a few hours before I saw your post. A sign? but it sells for over 100 USD!
thank's again for your explanation of your set up,
best regards,
Andreas
_________________
my photos on flickr: https://www.flickr.com/photos/kuuan/collections
Last edited by kuuan on Sun Jun 22, 2008 2:16 pm; edited 1 time in total |
|
| Back to top |
|
|
vilva
Joined: 04 Mar 2007
Posts: 785
Location: Porvoo/Borgå, Finland
Expire: 2015-05-27
|
| Posted: Sun Jun 22, 2008 2:13 pm Post subject: |
|
|
vilva wrote:
| kuuan wrote: |
| Viejo, tell me, do you know for how much this Pentax ajustable Close-up Ring usually sells for? |
Well, I wouldn't know the usual price. I got this one from eBay for GBP 15 + postage, which was cheap, I guess.
Veijo
_________________
Mainly Schneider-Kreuznach Radionar (1938), VPK Meniscus Achromat (1915), TTH Cooke Anastigmat (1917), TTH Cooke Aviar (1937), Goerz Dopp-Anastigmat III Dagor (1912), Voigländer Heliar (1928) or Aldis Uno Series III (1903 design) mounted on EOS 5D or EOS 350D |
|
| Back to top |
|
|
kuuan
Joined: 14 Jan 2008
Posts: 4588
Location: right now: Austria
Expire: 2014-12-26
|
| Posted: Sun Jun 22, 2008 2:18 pm Post subject: |
|
|
kuuan wrote:
thank's Viejo, and sorry I had edited my post asking also for further clarification on how you set your lens/focus just when you must have added your reply
thank's,
Andreas
_________________
my photos on flickr: https://www.flickr.com/photos/kuuan/collections |
|
| Back to top |
|
|
estudleon
Joined: 15 May 2008
Posts: 3791
Location: Argentina
|
| Posted: Sun Jun 22, 2008 2:30 pm Post subject: |
|
|
estudleon wrote:
[quote="Nesster"]Toenails our cat died last year, I remembered this photo because of the great Zuiko pics above... This is with the 85mm f/2.
[img]http://farm2.static.flickr.com/1374/1473579456_20acd0cedb_o.jpg[/img][/quote]
I like the bokeh very much. But i like more the expression of toenails. The subjet matter is the question of each shot, no? While the bokeh don't obstruct the principal idea of the pícture, is a taste quid.
_________________
Konica 2,8/100
CZJ: 4/20, 2,4/35, 1,8/50 aus jena, 3,5/135MC, Pentacon 1,8/50
Pentax S-M-C-1,4/50
Helios 44-3
Mamiya 2,8/135
Misc. : jupiter 9
Stuff used:
A) SRL
Alpa 10 D - kern macro Switar 1,9/50 -black, Kilffit apochromat 2/100.
Asahi pentax spotmatic super takumar 1,4/50
Contaflex super B tessar 2,8/50 Pro-tessar 115
Leica R3 electronic summicron 2/50 elmarit 2,8/35
Konica Autoreflex 3 (2 black and chrome one), TC, T4. 2,8/24, 3,5/28 not MC and MC, 1,8/40, 1,4/50, 1,7/50 MC and not MC, 1,8/85, 3,2/135, 3,5/135, 4/200
Minolta XG9 2,8/35, 2/45, 3,5/135
Nikkormat FTn 1,4/50, 2,8/135
Fujica ST 801, 605, 705n. 3,5/19, 1,4/50, 1,8/55, 4/85, 3,5/135.
Praktica MTL 5 and a lot of M42 lenses.
Voigtlander. Bessamatic m, bessamatix de luxe, bessamatic cs, ultramatic and ultramatic cs.
Skoparex 3,5/35, skopagon 2/40, skopar 2,8/50, skopar X 2,8/50, super lanthar (out of catalogue) 2,8/50, dinarex 3,4/90, dinarex 4,8/100, super dinarex 4/135, super dinarex 4/200, zoomar 2,8/36-83, portrait lens 0, 1 and 2. Curtagon 4/28 and 2,8/35
Canon AV1, 1,8/50
Rolleiflex SL35 and SL35 E. 2,8/35 angulon, 2,8/35 distagon, 1,4/55 rolleinar, 1,8/50 planar, 4/135 tessar, 2,8/135 rolleinar, x2 rollei, M42 to rollei adap.
Etc.
RF
Yashica Minister III
Voightlander Vito, vitomatic I, Vito C, etc.
Leica M. M2, M3 (d.s.) and M4. Schenider 3,4/21, 2/35 summaron 2,8/35 (with eyes). Summicron 2/35 (8 elements with eyes), 2/35 chrome, 2/35 black, 1,4/35 pre asph and aspheric - old -, 2/40 summicron, 2,8/50 elmar, 2/50 7 elements, 2/50 DR, 2/50 - minolta version, 1,4/50 summilux 1966 version, 1,4/75 summilux, 2/90 large version, 2/90 reduced version of 1987, 2,8/90 elmarit large version, 4/135 elmar. |
|
| Back to top |
|
|
estudleon
Joined: 15 May 2008
Posts: 3791
Location: Argentina
|
| Posted: Sun Jun 22, 2008 2:36 pm Post subject: |
|
|
estudleon wrote:
[quote="vilva"][quote="aoleg"][quote="vilva"]Here are some of my Radionar test shots.[/quote]
These shots look amazing and very different from modern, conventional lenses. I'd like to see your setup, too. Wonder if it's possible to assemble one.[/quote]
Thanks
Here is the setup used for the above photos:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/radionar_dual_focus_r.jpg[/img]
I have glued the Radionar (still mounted in the original shutter set at T) to a short M42 macro extension tube so that it is easy to change it between an M42 bellows and the Asahi Pentax Adjustable Close-Up Ring shown in the photo. The front cell of the lens is mostly used to adjust the image quality and the adjustable close-up ring to focus, which method allows any setting between a "normal" and a soft focus/bokeh. Here is an example pair of photos:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0865_s.jpg[/img]
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0867_s.jpg[/img]
and another couple of shots just to show the leeway:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0861_s.jpg[/img]
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0862_s.jpg[/img]
When extreme close-ups aren't desired or the highest possible contrast or resolution, this is one of my favorite lens systems, a most flexible one as you can see.
Veijo[/quote]
Fatntastic shots! I like the bit low contrast - not as low as natural way - not too saturated colors. The three elements play the game so well!!!!
_________________
Konica 2,8/100
CZJ: 4/20, 2,4/35, 1,8/50 aus jena, 3,5/135MC, Pentacon 1,8/50
Pentax S-M-C-1,4/50
Helios 44-3
Mamiya 2,8/135
Misc. : jupiter 9
Stuff used:
A) SRL
Alpa 10 D - kern macro Switar 1,9/50 -black, Kilffit apochromat 2/100.
Asahi pentax spotmatic super takumar 1,4/50
Contaflex super B tessar 2,8/50 Pro-tessar 115
Leica R3 electronic summicron 2/50 elmarit 2,8/35
Konica Autoreflex 3 (2 black and chrome one), TC, T4. 2,8/24, 3,5/28 not MC and MC, 1,8/40, 1,4/50, 1,7/50 MC and not MC, 1,8/85, 3,2/135, 3,5/135, 4/200
Minolta XG9 2,8/35, 2/45, 3,5/135
Nikkormat FTn 1,4/50, 2,8/135
Fujica ST 801, 605, 705n. 3,5/19, 1,4/50, 1,8/55, 4/85, 3,5/135.
Praktica MTL 5 and a lot of M42 lenses.
Voigtlander. Bessamatic m, bessamatix de luxe, bessamatic cs, ultramatic and ultramatic cs.
Skoparex 3,5/35, skopagon 2/40, skopar 2,8/50, skopar X 2,8/50, super lanthar (out of catalogue) 2,8/50, dinarex 3,4/90, dinarex 4,8/100, super dinarex 4/135, super dinarex 4/200, zoomar 2,8/36-83, portrait lens 0, 1 and 2. Curtagon 4/28 and 2,8/35
Canon AV1, 1,8/50
Rolleiflex SL35 and SL35 E. 2,8/35 angulon, 2,8/35 distagon, 1,4/55 rolleinar, 1,8/50 planar, 4/135 tessar, 2,8/135 rolleinar, x2 rollei, M42 to rollei adap.
Etc.
RF
Yashica Minister III
Voightlander Vito, vitomatic I, Vito C, etc.
Leica M. M2, M3 (d.s.) and M4. Schenider 3,4/21, 2/35 summaron 2,8/35 (with eyes). Summicron 2/35 (8 elements with eyes), 2/35 chrome, 2/35 black, 1,4/35 pre asph and aspheric - old -, 2/40 summicron, 2,8/50 elmar, 2/50 7 elements, 2/50 DR, 2/50 - minolta version, 1,4/50 summilux 1966 version, 1,4/75 summilux, 2/90 large version, 2/90 reduced version of 1987, 2,8/90 elmarit large version, 4/135 elmar. |
|
| Back to top |
|
|
estudleon
Joined: 15 May 2008
Posts: 3791
Location: Argentina
|
| Posted: Sun Jun 22, 2008 2:37 pm Post subject: |
|
|
estudleon wrote:
[quote="vilva"][quote="aoleg"][quote="vilva"]Here are some of my Radionar test shots.[/quote]
These shots look amazing and very different from modern, conventional lenses. I'd like to see your setup, too. Wonder if it's possible to assemble one.[/quote]
Thanks
Here is the setup used for the above photos:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/radionar_dual_focus_r.jpg[/img]
I have glued the Radionar (still mounted in the original shutter set at T) to a short M42 macro extension tube so that it is easy to change it between an M42 bellows and the Asahi Pentax Adjustable Close-Up Ring shown in the photo. The front cell of the lens is mostly used to adjust the image quality and the adjustable close-up ring to focus, which method allows any setting between a "normal" and a soft focus/bokeh. Here is an example pair of photos:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0865_s.jpg[/img]
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0867_s.jpg[/img]
and another couple of shots just to show the leeway:
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0861_s.jpg[/img]
[img]http://galactinus.net/vilva/retro/radionar_uf_files/scrad0862_s.jpg[/img]
When extreme close-ups aren't desired or the highest possible contrast or resolution, this is one of my favorite lens systems, a most flexible one as you can see.
Veijo[/quote]
Fantastic shots! I like the bit low contrast - not as low as natural way - not too saturated colors. The three elements play the game so well!!!!
_________________
Konica 2,8/100
CZJ: 4/20, 2,4/35, 1,8/50 aus jena, 3,5/135MC, Pentacon 1,8/50
Pentax S-M-C-1,4/50
Helios 44-3
Mamiya 2,8/135
Misc. : jupiter 9
Stuff used:
A) SRL
Alpa 10 D - kern macro Switar 1,9/50 -black, Kilffit apochromat 2/100.
Asahi pentax spotmatic super takumar 1,4/50
Contaflex super B tessar 2,8/50 Pro-tessar 115
Leica R3 electronic summicron 2/50 elmarit 2,8/35
Konica Autoreflex 3 (2 black and chrome one), TC, T4. 2,8/24, 3,5/28 not MC and MC, 1,8/40, 1,4/50, 1,7/50 MC and not MC, 1,8/85, 3,2/135, 3,5/135, 4/200
Minolta XG9 2,8/35, 2/45, 3,5/135
Nikkormat FTn 1,4/50, 2,8/135
Fujica ST 801, 605, 705n. 3,5/19, 1,4/50, 1,8/55, 4/85, 3,5/135.
Praktica MTL 5 and a lot of M42 lenses.
Voigtlander. Bessamatic m, bessamatix de luxe, bessamatic cs, ultramatic and ultramatic cs.
Skoparex 3,5/35, skopagon 2/40, skopar 2,8/50, skopar X 2,8/50, super lanthar (out of catalogue) 2,8/50, dinarex 3,4/90, dinarex 4,8/100, super dinarex 4/135, super dinarex 4/200, zoomar 2,8/36-83, portrait lens 0, 1 and 2. Curtagon 4/28 and 2,8/35
Canon AV1, 1,8/50
Rolleiflex SL35 and SL35 E. 2,8/35 angulon, 2,8/35 distagon, 1,4/55 rolleinar, 1,8/50 planar, 4/135 tessar, 2,8/135 rolleinar, x2 rollei, M42 to rollei adap.
Etc.
RF
Yashica Minister III
Voightlander Vito, vitomatic I, Vito C, etc.
Leica M. M2, M3 (d.s.) and M4. Schenider 3,4/21, 2/35 summaron 2,8/35 (with eyes). Summicron 2/35 (8 elements with eyes), 2/35 chrome, 2/35 black, 1,4/35 pre asph and aspheric - old -, 2/40 summicron, 2,8/50 elmar, 2/50 7 elements, 2/50 DR, 2/50 - minolta version, 1,4/50 summilux 1966 version, 1,4/75 summilux, 2/90 large version, 2/90 reduced version of 1987, 2,8/90 elmarit large version, 4/135 elmar. |
|
| Back to top |
|
|
vilva
Joined: 04 Mar 2007
Posts: 785
Location: Porvoo/Borgå, Finland
Expire: 2015-05-27
|
| Posted: Sun Jun 22, 2008 3:26 pm Post subject: |
|
|
vilva wrote:
| kuuan wrote: |
| could you elucidate further on your settings, e.g. comparing the first to the second photo of in your last post? |
In the first one the front cell was set at 1m, i.e. grossly mismatched relative to the focus distance. In the second one it was set at 3m or so, which is a good enough general purpose setting.
Veijo
_________________
Mainly Schneider-Kreuznach Radionar (1938), VPK Meniscus Achromat (1915), TTH Cooke Anastigmat (1917), TTH Cooke Aviar (1937), Goerz Dopp-Anastigmat III Dagor (1912), Voigländer Heliar (1928) or Aldis Uno Series III (1903 design) mounted on EOS 5D or EOS 350D |
|
| Back to top |
|
|
|
|
Search
Memberlist
Register
Profile
Log in to check your private messages
Log in
